High Pressure Mill
High Pressure Mill is based on five years research on the traditional grinding mills, the High Pressure Mill got national patent and CE certificate, features of high efficiency and energy saving. It is suitable for grind mineral to powder, which is widely used in the fields of metallurgy, building materials, chemical and mining industry and so on. The final product powder can reach 0.613mm(30mesh) to 0.033mm(425mesh).
YGM series high pressure suspension mill is mainly suitable for process various non-flammable, non-explosive ore materials with mohs hardness below 9.3 and humidity below 6%, such as metallurgy, construction materials, chemicals, ores, highway construction, hydroelectrical subjects and so on.
Features of of High Pressure Mill
1.Size of final product can be 0.613mm (30mesh) –0.033mm (425mesh). And a few of material powder can reach 0.013mm (1000 mesh).
2.Compared with the common Raymond grinding mill under the same power conditions, the capacity can be increased by 10%; moreover, under the performance of high-pressure springs, the rollers grinding pressure on raw materials can be raised by 800-1200kgf..
3.The dust-removing effect can fully conform to the national standard.
4.The final product size ranges from the maximum particle diameter of 0.613mm (30mesh) to the finest diameter of 0.033mm (425 mesh). A few materials can reach 0.013mm (1000 mesh).
Technical Parameter of High Pressure Mill
Mm to inch conversion: 25.4 millimeters=1 inch
The humidity and hardness of raw material will affect the fineness and capacity.
| Model | Piece of roller | Size of the roller (mm) | Size of the ring (mm) | Feed size(mm) | Fineness of powder (mm) | Capacity (t/h) | Motor power (kW) | Weight (without motor)(t) |
| YGM85 | 3 | Φ270×150 | Φ830×150 | ≤20 | 0.033-0.613 | 1.2-4 | 22 | 6 |
| YGM95 | 4 | Φ310×170 | Φ950×170 | ≤25 | 0.033-0.613 | 2.1-5.6 | 37 | 11.5 |
| YGM130 | 5 | Φ410×210 | Φ1280×210 | ≤30 | 0.033-0.613 | 2.5-9.5 | 75 | 20 |
Note:
1. Based upon limestone-grinding with 80% pass-through;
2. The final technical data are subject to the operation manual along with the machine.
Note: Any change of High Pressure Mill technical data shall not be advised additionally.
