JC Series Jaw Crusher
The JC series of European jaw crushers have been developed on basis of many years proven experience and can be used for secondary and fine crushing to process hard and abrasion mineral stones and rocks in metallurgy, mine, chemical, cement, building construction, fireproof material and ceramics industry. It is ideal crusher to crush the mineral stone, rock and slag with compression resistance below 280Mpa.
Features of JC Series Jaw Crusher
1.World-class advanced manufacturing techinics and materials of superior quality are adopted.
2.The jaw integration is the most advanced one, which makes the machine quite durable.
3.The draft classiss is of integrated cast steel structure.
4.Wiht the limited elements analysing technology, the crusher can gain a higher intensity.
5.The crushing cavity is of “V” type structure, which can make the actural inlet size quite the same as the nomical inlet size.
6.It’s more rapid and convinient to adjust the outlet.
7.The specification of drafts is bigger, which means a higher load.
8.Teeth-like protective plate is adopted, which will effectively lengthen the functional length of jaw plate and boost the capacity.
Technical Parameter of JC Series Jaw Crusher
Mm to inch conversion: 25.4millimeters=1 inch
Model | JC760×1100 | JC840×1100 | JC1100×1200 | JC180×1300 | |
Opening Size (mm) |
760×1100 | 840×1100 | 1100×1200 | 180×1300 | |
Max. Feed Size (mm) |
620 | 720 | 930 | 150 | |
Discharge Opening Range (mm) |
75-200 | 100-225 | 150-275 | 10-30 | |
Shaft Speed (r/min) |
270 | 240 | 210 | 320 | |
Capacity (t/h) | 150-350 | 200-500 | 300-650 | 12-35 | |
Motor | Power (kw) |
110-132 | 132-160 | 185-200 | 30-37 |
Speed (r/min) |
985 | 985 | 740 | 980 | |
Dimension (mm)(L×W×H) |
2600×2500 ×2200 |
3300×2320 ×3120 |
4140×2660 ×3560 |
1320×2150 ×1175 |
|
Weight (kg) | 24000 | 32000 | 59200 | 6000 |
Model | JC250×1000 | JC250×1300 | JC400×600 | |
Opening Size (mm) |
250×1000 | 250×1300 | 400×600 | |
Max. Feed Size (mm) |
220 | 220 | 350 | |
Discharge Opening Range (mm) |
20-40 | 70-100 | 35-85 | |
Shaft Speed (r/min) |
330 | 290 | 250 | |
Capacity (t/h) | 15-50 | 26-85 | 15-70 | |
Motor | Power (kw) |
30-37 | 37-45 | 37-45 |
Speed (r/min) |
980 | 980 | 980 | |
Dimension (mm)(L×W×H) |
1400×1850 ×1310 |
1450×2150 ×1175 |
1920×1460 ×1840 |
|
Weight (kg) | 5600 | 6800 | 7000 |
Note: Any change of European Type Jaw Crusher technical data shall not be advised additionally.
