PE Series Jaw Crusher
Jaw Crusher can be used to crush various mineral stones and bulk materials to medium size.
There are two types: coarse crushing and fine crushing, it will be the ideal equipment for primary crushing.Compare a KEFID jaw crusher with any other jaw crusher on the market. Immediately you’ll see this machine was built for demanding production, strength and a lifetime of dependability.
Features of PE Series Jaw Crusher
1.The crushing cavit is deep and without dead zone, which can increase the feeding capacity and capacity;
2.It has a big crushing ratio and even grain shape.
3.The gasket type inlet size makes flexible adjustment posible, and it’s reliable, conveinent, and with a big adjustment range,which can greatly enhance the flexibility of the equipments.
4.The lubrication system is safe and reliable, and it’s quite convinient to change components and there will be less maintenance needed.
5.It has a simple structure, and is quite stable and low in operation cost.
6.The equipment is energy saving: 15%-30% energy can be saved for each single plate, more than twice energy will be saved for the whole system.
Technical Parameter of PE Series Jaw Crusher
Mm to inch conversion: 25.4millimeters=1 inch
| Model | Max. Feeding Size (mm) |
Discharge Size (mm) |
Capacity (t/h) | Motor Power (kw) |
Overall Dimensions (mm) |
Weight (t) |
| PE400×600 | 350 | 40-100 | 15-60 | 30 | 1700×1732×1653 | 6.5 |
| PE500×750 | 425 | 50-100 | 50-100 | 55 | 2035×1921×2000 | 10.3 |
| PE600×900 | 480 | 65-160 | 60-130 | 75 | 2290×2206×2370 | 16.5 |
| PE750×1060 | 630 | 80-140 | 80-180 | 110 | 2620×2302×3110 | 29 |
| PE900×1200 | 750 | 95-165 | 140-260 | 110 | 3789×2826×3025 | 54.5 |
| PE1000×1200 | 850 | 195-265 | 315-550 | 110 | 3335×3182×3025 | 57 |
| PE1200×1500 | 1020 | 150-300 | 400-800 | 160-220 | 4200×3750×3820 | 100.9 |
Note: Any change of Jaw Crusher technical data shall not be advised additionally.
